xMASS SDR – 8×8 MIMO Transceiver for 4G/5G Applications to be Crowd Funded

Thank you to creators Sergey and Andrew who have submitted news about their upcoming software defined radio called 'xMASS SDR'. xMASS will be a SDR with 8 RX and 8 TX channels, with a max sample rate of 60 MSPS per 8 channels, or 100 MSPS per 4 channels, and a frequency range of 30 - 3800 MHz.

The board comes in a modular PCIe form factor, with 4x FPGAs, and GPS/PPS clock sync input. The system is designed in mind for 4G/5G applications but should be useful for other applications too.

xMASS SDR will be crowd-funded on CrowdSupply, and they note that they expect to launch the campaign soon. So if you are interested, sign up for email updates on their CrowdSupply page.

Sergey and Andrew write:

We’re creators (Sergey Kostanbaev and Anrew Avtushenko) of the M.2 uSDR board that we successfully crowdsourced a year ago. Now we want to share our new invention called xMASS SDR, a modular, high-performance MIMO transceiver. It has 8 RX and 8 TX channels that can be synchronized for directional finding, beamforming and more applications. Each SDR module, called xSDR, is based on the LMS7002M chip and can deliver 2 RX and 2 TX channels. Like uSDR, xSDR shares the same form factor and M.2 pinout and both use the same open-source software and gateware stack.

xMASS SDR is ideal for 4G/5G but can be interesting among academic, industrial and advanced hobbyists.

The xMASS SDR board connected via PCIe on a motherboard.
The xMASS SDR board connected via PCIe on a motherboard.
The xMASS SDR board with 4x uSDR modules by itself.
The xMASS SDR board with 4x modules by itself.

uSDR Software Updated to V1.7.0

Thank you to Viol for writing in and letting us know that his uSDR software has recently been updated to V1.7.0. The uSDR software (not to be confused with the unrelated uSDR hardware) is a lightweight general-purpose multimode program for Windows that supports the RTL-SDR, Airspy, BladeRF, HackRF, LimeSDR, and other SDR radios.

Viol highlights the latest features added in the 1.7.0 update below:

  • Fobos SDR frontend native support, the very new SDR from RigExpert
  • bladeRF API v2.5.0 support, oversampling mode up to 122.88 MHz sample rate (do not forget to update FX3 firmware)
  • advanced IQ playback mode, precise timing and streaming
  • improved DSP routines and memory management, minimized CPU load
  • excellent ruler tool for spectrum frequency and amplitude measurements
uSDR Updated to Version 1.7.0. Images shows FobosSDR support.
uSDR Updated to Version 1.7.0. Images shows FobosSDR support.

CrowdFunding for the uSDR has started: A $299 M.2 TX/RX 300-3700 MHz, 30.72 MSPS SDR

Back in May we posted about pre-release news of the uSDR, a duplex TX & RX capable software defined radio, with a frequency range of 300-3700 MHz, and up to 30.72 MSPS of sampling rate. It also has an interesting defining feature in that it can be controlled via a web browser and that it connect via an M.2 slot (with a USB adapter available too).

The uSDR recently started it's crowd funding phase on CrowdSupply a few hours ago. It is priced at $299 for the uSDR board, with various adapters and antennas also available for purchase.

The CrowdSupply page has been updated and includes full details about the SDR, noting it's use of the LMS6002 SDR chip from Lime Microsystems and a Xilinx Artix 7 XC7A35T FPGA.

They also show screenshots of their web software which is looking pretty slick. It appears that you can instantiate various apps from the web interface. The apps include a 2G cellular network, FM receiver, IQ generator, IQ playback, frequency spectrum monitor, device sharing, signal analyzer, signal inspector and spectrogram.

uSDR. A Tiny M.2 single component SDR controlled from a Web browser

uSDR. Cellular network in a browser



uSDR: A TX/RX 300-3700 MHz, 30.72 MSPS Capable SDR with M.2 Interface and Web Browser Control

Over on CrowdSupply a new SDR called "uSDR" created by Wavelet SDR has been announced (not to be confused with the uSDR software). uSDR is a tiny SDR that interfaces via an M.2 slot on a PC/laptop motherboard. Typically M.2 slots are what you would use to connect a solid-state drives (SSD), but can also be used for adding expansion cards. However, a simple M.2 to USB adapter could be used to convert it into dongle form.

The uSDR is advertised of being a duplex TX & RX capable SDR, with a frequency range of 300-3700 MHz, and up to 30.72 Msps of sampling rate. It also has a 0.5 PPM TCXO. To keep it's tiny form factor, it uses small MHF4 antenna connectors.

The device appears to be based on the AMD Xilinx ARTIX-7 FPGA and the LimeMicro LMS6002 transceiver IC.

One interesting differentiating feature of the uSDR is that it is designed to be operated via it's web interface which can be accessed through Chrome. They make use of WebUSB technology, which allows Chrome to directly connect to USB devices. This should help eliminate installation and compatibility issues, and allow the SDR to easily be used over a network. Apart from the web interface it is also compatible with SoapySDR and GNU Radio. Sergey, one of the creators of uSDR wrote:

During development we focused on ease of use, thus it supports WebUSB interface. Meaning you can view Spectrogram, record or playback IQ data, do some signal analysis and even share your device over the internet to get others access to it. And all this doesn’t require any software or specific drivers and works in Linux/Windows/Mac OS/Android and more. One can even extend these applications and run their own.

The device is single channel covering a range ~230MHz-3.7GHz for TX / RX and we’re making it affordable. Last but not least you still can use this device with SoapySDR as a regular SDR.

The project is currently in it's early stages, with Crowd Funding expected to begin soon. Pricing is still unknown, however Sergey did mention that it will be affordable. Subscribe for announcements via their CrowdSupply page.

uSDR: A tiny, single-sided M.2 SDR board that you can operate easily using your web browser
uSDR web platform. FM Receiver showcase

uSDR Updated to Version 1.6.0

Thank you to Viol for submitting news about the latest update of his uSDR software. uSDR (aka microSDR) is a lightweight general purpose multimode program for Windows that supports the RTL-SDR, Airspy, BladeRF, HackRF and LimeSDR radios. Viol highlights the latest features in the new update below:

  • Airspy HF+ Discovery frontend support
  • ExtIO*.dll interface support. Copy ExtIO*.dll and all dependencies to the root folder and have a fun
  • ExtIO_USRP.dll and all dependencies for USRP B210 included. Just install Zadig libusb driver and go
  • LimeSDR multiple frontends switch fixed
  • FM demodulator with inverted audio spectrum
  • DCS decoder
  • additional C/C++ source examples for remote IQ passband processing TCP client
  • advanced IQ file playback options
  • display hold peak spectrum mode, zoomable and panable plot, customized colors

As always all descriptions, screenshots and binaries could be found on

https://sourceforge.net/projects/u-sdr/

uSDR aka microSDR. A lightweight SDR receiver program for Windows.

Lightweight Windows Software uSDR Updated to Version 1.5.0

Since 2021 we've posted about Viol Tailor's "uSDR" (microSDR) software a couple of times. uSDR is a lightweight general purpose multimode program for Windows that supports the RTL-SDR, Airspy, BladeRF, HackRF and LimeSDR radios. The software can be downloaded from SourceForce.

Viol notes that recently the project has been updated to V1.5.0 which brings the following new features and changes.

  • lock device frequency on zoom option
  • keep waterfall history – the very great option, do not lose any rare signals
  •  advanced passband IQ recorder
  • passband IQ TCP server for remote processing, C/C++ client source examples included
  • advanced audio player, auto selectable sample rate, separate left/right channels
  • CTCSS decoder
  • markers import option convenient for merge markers
  • Ctrl+Shift+Drag Up/Down – change spectrum magnitude offset
  • Ctrl+Shift+Mouse Wheel – change spectrum magnitude range (vertical zoom)
  • Ctrl+Mouse Hover – highlight nearest marker
  • Ctrl+Double Click– tune to highlighted nearest marker
  • band plan visualization, simple text format
  • frontend interface improvements
  • GUI improvements
  • spectrum and waterfall popup menus improvements
  • a lot of bug fixes
uSDR aka microSDR. A lightweight SDR receiver program from Windows.

Lightweight Windows Software uSDR Updated to Version 1.4.0

Back in July we posted about the release of Viol Tailor's "uSDR" software, which is a lightweight general purpose multimode program for Windows which supports the RTL-SDR, Airspy, BladeRF, HackRF and LimeSDR radios. Recently Viol has updated the software to V1.4.0. The new release brings SDRplay support, and various performance and GUI improvements listed below.

The software can be downloaded from SourceForce.

  • customizable tool panel behavior (fixed, floating, undocked)
  • SDRPlay frontend support (API v.2.13)
  • RTL-TCP streaming interface support, presets quick switch (server, port, description)
  • high precision Wav IQ file play back
  • support RIFF 8, 16, 24 and 32 bits integer, 32 bits float, FR64 file formats for playback
  • recognize Wav IQ file central frequency for play back
  • frequency offset (shift) for x-verters
  • swap IQ (invert spectrum) option
  • improved FFT spectrum calculation and visualization
  • waterfall color map range may be changed manually on the spectrum window as well as on tool panel, also included the auto scale option
  • color map palette can be customized and fast switched, palette presets are included
  • FIFO buffer size (IQ history time) may be changed on the fly, all memory allocations are under hood, no losses of previously stored history
  • pass band may be attachment to global frequency as well as to local baseband frequency or to screen position
  • squelched threshold control and level indicator for demodulation (in addition to adjustable spectrum threshold detector)
  • stereo FM demodulator
  • low latency audio
  • frequency manager, groups and interactive markers, visualize, edit, navigate, tune the pass band
  • spectrum and waterfall popup menus
  • improved GUI controls
  • "fine tune" option: set pass band to rounded frequency (spectrum right click)
  • statistics visualization window
uSDR aka microSDR. A lightweight SDR receiver program from Windows.

uSDR: A Lightweight Multimode SDR Receiver Program for Windows

Thank you to Viol Tailor for submitting news about the release of his general purpose multimode software defined radio receiver program for Windows called "uSDR" or "microSDR". Viol writes that uSDR is designed as a lightweight binary with a simple and compact user interface and highly optimized DSP to minimize CPU, hence the "micro" part of the name.

The software is compatible with RTL-SDR, Airspy, BladeRF, HackRF and LimeSDR radios. It has features including demodulation, base band and pass band recording, playback, and spectrum and waterfall visualizations.

uSDR aka microSDR. A lightweight SDR receiver program from Windows.
