OpenEar Now Supports TETRA, DMR, POCSAG, ADS-B

Back in March we posted about "OpenEar" which was a newly released Windows TETRA decoder for RTL-SDR dongles. Back then the author "moneriomaa" noted that he planned to add several new modes. In the release that is currently available, OpenEar now supports TETRA, DMR, Pocsag, ADS-B as well as standard AM and NFM modes. We tested the software, and all modes appear to decode as advertised. In the future the author plans to add more modes such as MPT-1327 and AERO.

In the previous post we added an update noting that OpenEar appeared to be violating the GPL licence of OsmocomTETRA, and the author noted that he would remove the TETRA functionality until licencing was resolved. As TETRA decoding is back in the recent releases we assume these legal issues have been solved.

In the current release you also need to provide your own rtlsdr.dll file, which can be obtained from your SDR# folder, or directly from the Osmocom windows release (rename librtlsdr.dll to rtlsdr.dll).

Latest OpenEar Version
Latest OpenEar Version

DSDPlusUI: A Graphical User Interface for DSD+

Over on Twitter Annunaki (@StupotSinders) has been teasing some screenshots of a GUI for DSD+ that he's been developing over the past few weeks. And now he has released the software which is called "DSDPlusUI". DSD+ is mostly command line based, so a GUI could be useful for newbies. The software can be downloaded from the DSDPlusUI groups.io page.

DSD+ (aka Digital Speech Decoder) is a free closed source program that is compatible with RTL-SDR and various other SDRs which is used to decoder digital speech protocols such as P25 P1, DMR, NXDN and more. DSD+ Fastlane is a paid upgrade which allows subscribers to receive the latest updates to the software early.

DSD+ GUI by Annunaki
DSD+ GUI by Annunaki

Radio Analyser: New Program for Plotting DSDPlus Statistics

Thank you to Matthew Cowley for submitting news about his new program called "Radio Analyser". Radio Analyser is a program that imports DSDPlus radio and group files into a postgresql database. The data can then graphed on the web interface allowing you to view talk group and radio statistics. DSDPlus is a program that can be used to listen in to digital P25, DMR and other digital voice protocols with an RTL-SDR or similar SDR.

Matthew writes the following, and some screenshots of the interface and graphs are shown in the slider and the end of the post:

I've been learning Ruby on Rails and as a first project I wrote a project that you host at home which imports the DSDPlus.radios and DSDPlus.groups files and displays their activity in graph form. It will show you total site activity, talk group activity and radio activity.

OpenEar Now Supports TETRA, DMR, POCSAG, ADS-B

Back in March we posted about "OpenEar" which was a newly released Windows TETRA decoder for RTL-SDR dongles. Back then the author "moneriomaa" noted that he planned to add several new modes. In the release that is currently available, OpenEar now supports TETRA, DMR, Pocsag, ADS-B as well as standard AM and NFM modes. We tested the software, and all modes appear to decode as advertised. In the future the author plans to add more modes such as MPT-1327 and AERO.

In the previous post we added an update noting that OpenEar appeared to be violating the GPL licence of OsmocomTETRA, and the author noted that he would remove the TETRA functionality until licencing was resolved. As TETRA decoding is back in the recent releases we assume these legal issues have been solved.

In the current release you also need to provide your own rtlsdr.dll file, which can be obtained from your SDR# folder, or directly from the Osmocom windows release (rename librtlsdr.dll to rtlsdr.dll).

Latest OpenEar Version
Latest OpenEar Version

DSDPlusUI: A Graphical User Interface for DSD+

Over on Twitter Annunaki (@StupotSinders) has been teasing some screenshots of a GUI for DSD+ that he's been developing over the past few weeks. And now he has released the software which is called "DSDPlusUI". DSD+ is mostly command line based, so a GUI could be useful for newbies. The software can be downloaded from the DSDPlusUI groups.io page.

DSD+ (aka Digital Speech Decoder) is a free closed source program that is compatible with RTL-SDR and various other SDRs which is used to decoder digital speech protocols such as P25 P1, DMR, NXDN and more. DSD+ Fastlane is a paid upgrade which allows subscribers to receive the latest updates to the software early.

DSD+ GUI by Annunaki
DSD+ GUI by Annunaki

Radio Analyser: New Program for Plotting DSDPlus Statistics

Thank you to Matthew Cowley for submitting news about his new program called "Radio Analyser". Radio Analyser is a program that imports DSDPlus radio and group files into a postgresql database. The data can then graphed on the web interface allowing you to view talk group and radio statistics. DSDPlus is a program that can be used to listen in to digital P25, DMR and other digital voice protocols with an RTL-SDR or similar SDR.

Matthew writes the following, and some screenshots of the interface and graphs are shown in the slider and the end of the post:

I've been learning Ruby on Rails and as a first project I wrote a project that you host at home which imports the DSDPlus.radios and DSDPlus.groups files and displays their activity in graph form. It will show you total site activity, talk group activity and radio activity.

Some tips on using DSD+ and SDR# to Listen to DMR Digital Voice

Over on YouTube user knoxieman has uploaded a video that provides a few tips on using DSD+ and an RTL-SDR for listening to DMR digital voice signals. The video is designed as a companion to Tech Minds' video which shows a full set up procedure for DSD+.

Knoxieman's video includes some tips on SDR# settings, virtual audio cable setup, and using a program called "DisplayFusion" to keep the DSD+ event windows permanently on top of the SDR# window.

Tips on using SDR Plus and DSDPLUS to listen to DMR/DIGITAL conversations.

Creating a Wireless Pi-Star Nextion Display for Amateur Digital Radio

Thanks to Steve K2GOG of The Hudson Valley Digital Network (HVDN) for submitting his post on how to create a wireless display for Pi-Star. Pi-Star is a pre-built Raspberry Pi image for amateur radio users experimenting with digital voice communications like D-STAR and DMR. They write that it can be used for applications such as a "single mode hotspot running simplex providing you with access to the increasing number of Digital Voice networks, [or a] public duplex multimode repeater".

Pi-Star is compatible with serial based LED displays with built in GUIs like the Nextion. The displays are usually connected directly to the Raspberry Pi, but Steve wanted to use the display remotely. To do this he used a simple and inexpensive 70cm band HC-12 wireless serial port adapter. With the wireless adapters connected to the Pi he was able to see the pulses in SDR# via his RTL-SDR to confirm that the wireless serial signal was being sent. He then connected the second wireless adapter to the Nextion display via a few diodes to drop the voltage, and was able to get the display updating as if it was connected directly.

In the post Steve mentions that HVDN are also giving away an HC-12 and RTL-SDR to the first person to submit some progress with this idea.

Creating a wireless Nextion Display for Pi-Star.
Creating a wireless Nextion Display for Pi-Star.

Listening To Multiple DMR Channels with DSD+ and a HackRF on Linux

Thanks to Tony C who wrote in and wanted to share a method that he's found to listen to  multiple DMR digital voice channels in Linux. DSD+ is a Windows program that can be used to decode DMR. Although for Windows it is possible to use in Linux via the emulator known as Wine, and pipe the digital audio to it from GQRX. In the quote below, DSD+ "FL" is short for "Fast Lane" which is DSD+'s paid beta service that you can join to get  newer code with more features. Tony writes:

I believe that can bridge the gap between using Linux with the ease of use programs of windows. As I am sure we both can attest that setting up trunk tracking / anything SDR is not as easy on Linux as it is on windows. For example, DSDplus FL makes it extremely easy to identify/decode DMR networks. There are similar things that can be done on Linux, but as I stated, it isn’t as easy to setup.

So the method that I setup and have been using successfully, using Ubuntu and a HackRF, setting up DSDplus 2.98 on wine, that gets audio piped from GQRX using a virtual sink as outlined in https://www.hagensieker.com/wordpress/2018/04/29/dsd-in-ubuntu-18-04/. It was a great blog, but I felt that it was incomplete when trying to get all the voice traffic passed on a network, as it only works on 1 channel at a time.

So I found the control channel for the network and created 5 bookmarks in GQRX and gave them the tag “DMR”. From there I downloaded gqrx scanner https://github.com/neural75/gqrx-scanner followed the install and setup instructions. From there I activated the scanner and GQRX will cycle through the frequencies and when voice traffic is passed, it will stop, and DSDPLUS via wine will decode and record the audio.

[The screenshot] example was for P25, but it has worked in connect+ as well, the only thing is that you cannot bookmark the control channel. I know other options exist out there such as SDRtrunk / op25 which I have used, but I believe this provides a good alternative to those who have used windows and are comfortable with the ease of use of dsdplus FL but want to be on the Linux OS.

DSD+ Decoding Multiple DMR Channels on Linux
DSD+ Decoding Multiple DMR Channels on Linux



Video Tutorial: Setting up DMR Decoding with SDR#, DSD+ and an RTL-SDR

Over on YouTube user Tech Minds has uploaded a useful video which shows how to set up DMR decoding with SDR#, VB-Cable, DSD+ and an RTL-SDR dongle. He also uses the DSD plugin for SDR# which makes controlling the command line DSD+ software a little easier. If you are interested we also have a short tutorial on DMR/P25 decoding available here. The video starts from downloading and installing the software, and explains every step very carefully, so it is a very good starting video for beginners.

DMR (aka MotoTRBO or TRBO) is a digital voice protocol used by Motorola radios. Software like DSD+ is required to listen to it, but it can only listen in if the signal is unencrypted.

Tech Minds has also uploaded several other tutorial videos to his channel over the last few months including guides on how to set up the ham-it-up upconverter, ADS-B tracking, using a Raspberry Pi to create a FM transmitter and more.

How To Setup SDR # Sharp To Decode DMR Digitial Using DSD Plus And An RTL SDR Receiver on Windows 10

A Tutorial on using SDRAngel for DMR, D-Star and Fusion Reception with an RTL-SDR

At the end of last month we uploaded a post highlighting the SDRAngel software, which is a general purpose SDR program with some interesting features such as built in digital speech decoders for DMR, D-Star and Fusion. This avoids the need to pipe audio into a separate digital speech decoder program such as DSD+. SDRAngel also has transmit capabilities which makes it useful for SDRs such as the HackRF, PlutoSDR, LimeSDR etc.

Now over on YouTube and his blog K2GOG has uploaded a video tutorial about using SDRAngel. The tutorial starts with installing SDRAngel and explaining that you'll need a 64-bit system and OS to run it. He then goes on to show how to do FM reception and finally how to do digital speech decoding.

SDRangel K2GOG
